Definitions & Formulae

Definitions and Formulae

Aperture (w)





Wire Diameter (d)





Mesh Count (n)







Pitch (p)





Warp





Weft





Open Area %





Porosity

Space between adjacent parallel wires, in mm.

(25.4 / n) – d



Diameter of wire before weaving, in mm.





Number of apertures per lineal inch measured from the centre of one wire to a point 1 inch (25.4 mm) distant.

25.4 / (w + d)



Distance between the centres of two adjacent wires in mm.

w + d or 25.4 / n



Wires running lengthwise in the cloth as woven.





Wires running crosswise in the cloth as woven.





The fractional open surface area of the wirecloth in the flow direction

(w²) / (w + d)² * 100 (applicable for square meshes only).



The fractional void volume of the mesh.
