Specifications List

Specifications List

With a fast turning inventory of approximately 200,000 square metres of wirecloth, short lead times are guaranteed for standard items with same day despatches available for stock rolls and pieces.

Dedicated stocks of bespoke weaves, high volume demand materials and finished components can be arranged as required.

As wirecloth can potentially be woven in a limitless combination of aperture and wire diameter, in any width up to 10 metres, and in any weavable alloy, the lists below only represent the most commonly requested specifications many of which are normally available from stock in Stainless Steel up to 1524mm (60”) wide.

Plain Weave Standard Square Mesh Specifications

Mesh
Count
Warp
Size
Aperture
(mm)
% Open
Area
Approx.
kg/m2
22.00010.70071%3.97
21.60011.10076%2.54
32.0006.46758%5.96
31.6006.86766%3.82
31.4007.06770%2.92
42.0004.35047%7.95
41.6004.75056%5.09
41.2005.15066%2.86
51.6003.48047%6.36
51.2003.88058%3.58
51.0004.08065%2.48
61.6002.63339%7.63
61.2003.03351%4.29
61.0003.23358%2.98
60.9003.33362%2.41
60.7103.52369%1.50
70.9002.72957%2.82
70.8002.82961%2.23
70.7102.91965%1.75
81.6001.57522%10.17
81.2001.97539%5.72
80.7102.46560%2.00
80.6302.54564%1.58
100.9001.64042%4.02
100.7101.83052%2.50
100.6001.94058%1.79
100.5601.98061%1.56
100.5002.04065%1.24
120.8001.31739%3.82
120.6001.51751%2.15
120.5601.55754%1.87
120.4501.66762%1.21
140.6001.21445%2.50
140.5001.31452%1.74
140.4501.36457%1.41
140.3151.49968%0.69
160.6300.95736%3.15
160.5601.02742%2.49
160.4501.13851%1.61
160.4001.18856%1.27
160.3551.23260%1.00
160.2361.35272%0.44
180.5000.91142%2.24
180.4001.01151%1.43
180.2361.17569%0.50
180.2291.18270%0.47
200.5600.71031%3.12
200.4500.82042%2.01
200.4000.87047%1.59
200.3550.91552%1.25
200.2201.06069%0.48
220.2000.95568%0.44
240.4500.60833%2.41
240.3550.70344%1.50
240.3000.75851%1.07
240.2000.85866%0.48
240.1900.86867%0.43
260.2000.77763%0.52
280.3550.55237%1.75
280.3150.59243%1.38
300.3550.49234%1.88
300.3150.53239%1.48
300.3000.54742%1.34
300.2800.56745%1.17
300.1650.68265%0.41
300.1600.68766%0.38
320.1600.63464%0.41
340.1650.58261%0.46
360.2500.45642%1.12
360.2240.48247%0.90
360.1600.54660%0.46
380.1600.50057%0.48
380.1140.55469%0.25
400.2500.38537%1.24
400.2240.41142%1.00
400.2240.41142%1.00
400.1900.44549%0.72
400.1320.50363%0.35
440.1400.45058%0.43
460.1600.40051%0.59
500.2200.28832%1.20
500.2000.30837%0.99
500.1900.31839%0.90
500.1500.35850%0.56
520.1400.34851%0.51
580.1140.32455%0.37
600.1900.23330%1.08
600.1700.25336%0.86
600.1650.25837%0.81
600.1600.26339%0.76
600.1140.30953%0.39
620.1120.29853%0.39
700.1500.21334%0.78
700.1250.23843%0.54
700.1000.26352%0.35
700.0760.28762%0.20
740.0940.24953%0.32
800.1400.17831%0.78
800.1320.18634%0.69
800.1250.19237%0.62
840.0900.21249%0.34
840.0630.23963%0.17
880.0900.19947%0.35
940.0900.18044%0.38
1000.1120.14231%0.62
1000.1000.15437%0.50
1000.0900.16442%0.40
1000.0560.19861%0.16
1050.0800.16245%0.33
1080.0750.16046%0.30
1200.0900.12233%0.48
1200.0800.13239%0.38
1200.0630.14949%0.24
1240.0650.14047%0.26
1300.0430.15261%0.12
1340.0650.12543%0.28
1400.0800.10131%0.45
1450.0560.11946%0.23
1500.0710.09834%0.38
1500.0650.10438%0.31
1500.0600.10942%0.27
1500.0340.13564%0.09
1600.0360.12360%0.10
1650.0500.10446%0.20
1800.0600.08133%0.32
1800.0500.09142%0.22
1800.0300.11162%0.08
1950.0400.09048%0.16
2000.0500.07737%0.25
2000.0400.08747%0.16
2000.0280.09961%0.08
2300.0360.07445%0.15
2300.0280.08256%0.09
2500.0400.06237%0.20
2500.0250.07757%0.08
2700.0400.05433%0.21
2700.0360.05838%0.17
3000.0400.04528%0.24
3000.0360.04933%0.19
3000.0300.05542%0.13
3250.0360.04229%0.21
3250.0280.05041%0.13
4000.0250.03837%0.12
4000.0300.03428%0.18
5000.0250.02626%0.16

Twill Weave Standard Square Mesh Specifications

Mesh
Count
Warp
Size
Aperture
(mm)
% Open
Area
Approx.
kg/m2
2500.040.0620.370.2
2700.040.0540.330.21
3000.040.0450.280.24
3000.0360.0490.330.19
3250.0360.0420.290.21
4000.0250.0390.370.12
4000.030.0340.280.18
5000.0250.0260.260.16

Plain Dutch Weave Standard Square Mesh Specifications

Warp
Count
Weft
Count
Warp
Size
Weft
Size
Nominal
(microns)
Absolute
Range
Porosity
%
Kg/m2
12640.5800.400300260-28062%3.64
12720.4000.380300260-28062%3.50
16800.4300.340200210-23057%3.05
241100.3550.250120112-12560%2.70
301500.2300.1809090-10560%1.60
402000.1800.1407070-7559%1.30
502500.1400.1146056-6359%1.00
804000.1250.0714040-4555%0.81

Twill Dutch Weave Specifications

Warp
Count
Weft
Count
Warp
Size
Weft
Size
Nominal
(microns)
Absolute
Range
Porosity
%
Kg/m2
807000.1000.0772534-3640%1.20
1658000.1000.0771524-2847%0.71
16514000.0680.0401015-1837%0.72
20014000.0680.040511-1333%0.75
32523000.0360.02527-834%0.47

Reverse Plain Dutch Weave Specifications

Warp
Count
Weft
Count
Warp
Size
Weft
Size
Nominal
(microns)
Absolute
Range
Porosity
%
Kg/m2
128360.2020.4008095-10555%2.70
170500.1500.3006082-9054%2.05
290750.0900.2004050-5553%1.31
6251240.0400.1301725-3255%0.80

Twill Reverse Dutch Weave Specifications

Warp
Count
Weft
Count
Warp
Size
Weft
Size
Nominal
(microns)
Absolute
Range
Porosity
%
Kg/m2
132160.3550.457250210-26045%4.90
260400.1500.22012580-9553%1.95
325400.1500.3005545-7543%2.70
4001200.0650.1006060-7061%0.70

Five Shed Twill Weave Specifications

Warp
Count
Weft
Count
Warp
Size
Weft
Size
Aperture
(mm)
Open Area
%
Kg/m2
30180.5000.5000.347x0.91160-702.98
46180.5000.5000.052x0.91145-753.97
55350.3000.3000.162x0.42680-952.00
108590.1600.1600.075x0.271210-2601.05
